System Specifications
- CPU: Allwinner H618 | Quad-core | ARM Cortex™-A53
- GPU: Mali-G31
- RAM: 2GB
- STORAGE: 16GB
- OS: ATVSE Android 12
- Voltage: DC IN 5V/2A
- Power Consumption: 8W Max
- Operation Temperature: 0~40℃
- Humidity: <95%
I/O
- Video Output: HDMI2.0(4K60)
- Network: Buildin Wi-Fi antenna, Support USB RJ45 adaptive
- Peripheral Interface: USB2.0
- Power Interface: Type C USB (5V2A)
- Other Interface: IR receiver port
Features
- Network Streaming: HTML5, RTSP, HLS, Smooth streaming
- Multi-screen interactive: Miracast, DLNA and Airplay
- Local Media Playback: Video/Audio/Picture
- TV APP: Google Play(TV version), Google Voice Assistant, YouTube(4K), Netflix(TV Version), Disney+(TV Version), HBO, Max(TV Version), Other Android TV APP
- External Storage: USB storage max to 2TB (FAT32/NTFS)
- System Upgrading: Upgrading via USB disk or internet
|
Video
-
- H.265 Main10@L5.1 decoder up to 4K@60fps
- VP9 Profile 2 decoder up to 4K@30fps
- AVS2 JiZhun 10bit decoder up to 4K@30fps
- H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps
- Multi-format 1080p@60fps video playback formats, including H.264 BP/MP/HP, H.263 BP, VP8, MPEG-1 MP/HL, MPEG-2 MP/HL, MPEG-4 SP/ASP@L5, AVS+/AVS JiZhun, WMV9/VC1, etc
- Format: MKV, TS, M2TS, MOV, MP4, RM, RMVB, AVI, MPG, MPEG, DAT, VOB, FLV etc.
Audio
- Decoder: MPEG 1/2/2.5, Audio Layer 1/2/3, WMA Version 4/4.1/7/8/9, WMA Pro, LPCM, PCM, Vorbis, Flac, ALAC, APE, AACLC/HEAAC/HE-AAC v2, Real Audio, MPEG-H
- Format: MP3, WMA, WAV, OGG, M4A, MP4, AAC, APE, FLAC, ALAC, MPEG, MP1, MP2, MPA etc.
- Subtitle Format: SMI, SRT, SSA, ASS,SUB, SUB+IDX, ISO Navigation
- Photo Format: HD JPEG/BMP/GIF/PNG/TIFF
|
